Brushing (grinding) machine SD-3
€179 000
PURPOSE:
Designed for artificial aging (browning) of wooden blanks of any size.
APPLICATION:
Furniture manufacturing, joinery, and other woodworking industries.
Delivery methods
- We ship by any transport company or pick up yourself
Description
PURPOSE:
Designed for artificial aging (browning) of wooden blanks of any size.
APPLICATION:
Furniture manufacturing, joinery, and other woodworking industries.
ADVANTAGES:
– Simultaneous processing of the workpiece with three brushes (two metal brushes and an abrolone brush);
– Italian-made STM gearbox;
– Automatic workpiece feeding (German conveyor belt);
– Inverter for brush rotation – the machine can be used as a grinder (SD-2i model);
– Smoothly adjustable workpiece feed speed from 2 to 12 m/s;
– Separate motor for each unit;
– Czech-made components (brushes);
– Separate reverser for each working brush;
General and technical specifications:
| Electric motion. | 3 pcs. x 1.5-2.0 kW/950 rpm. |
| Frequency converter* (optional SD-3i mod.) | 700-1500 rpm*3 pcs. |
| Conveyor motor power | 0.37 kW |
| Power supply voltage | 3 phase/380V/50Hz |
| Number of shafts | 3×200 mm |
| Tool outer diameter | 150-250 mm |
| Max. Workpiece Width | 200 mm |
| Speed Adjustment | 1-12 m/min. |
| 3 Exhaust Hoods with a Diameter | 120 mm |
| Total Weight | 850 kg |
| Dimensions L/W/H | 2000 x 1250 x 1550 mm |
The warranty period for the supplied products is 1 year.
